Skywalker STRC149G09 - Page 25

Lower Enclosure Tube(6)
Upper Enclosure Tube(6)
Safety Placard sewn (1)
M10 Spring Washer (16)
PARTS LIST
#
17
FoamTubes (12)
19
22
21
U
tools
M10 Washer (48)
M10x98mm Bolt (16)
13
10
M10x20mm Bolt (16)
M10 Locknut (32)
14
16
18
23
Pole Cap(6)
Springs (82)
6
15
M4.8x16 Screw (18)
Pole retaining pin (6)
M5x50mm Bolt (6)
20
10
21
Straight Frame Tube(2)
11
Long Frame Tube (2)
M10x90mm Bolt (16)
12
24
Outer U-Joint(8)
25
28
27
26
Inner U-Joint(8)
Inner Cap(6)
25
