12
STEP 9
Now, repeat step 8 on the other side of the trampoline. Make sure to count
the exact number of V-rings and frame holes so each one corresponds!
You now have attached 2 V-rings to the frame holes using 2 springs.
Springs (x1)
8
STEP 10
Find the 4 T-joints indicated below and place a spring into the V-ring just left
of the T-joints, and stretch the spring until it reaches the frame hole just left
of the T-joints.
You now have attached 6 V-rings to the frame holes using 6 springs.
Springs (x4)
8
Enclosure door
(8)
T-joint
T-joint
(8)
Enclosure door
ASSEMBLY
To Next Page
