13
STEP 11
Next, place 6 springs into the V-rings just left of the 6 remaining sockets,
and stretch the springs until they reach the frame holes just left of the
sockets.
You now have attached 12 V-rings to the frame holes using 12 springs. There
should be 7 V-rings and 7 frame holes in between each spring.
Springs (x6)
8
STEP 12
Now, place one spring directly to the left of each spring already placed.
Continuing in a clock-wise direction, attach the remaining springs to the
remaining V-rings and frame holes until all 96 springs have been placed.
Springs (x84)
8
Socket
(8)
Enclosure door
13th
14th
15th
16th
17th
18th
19th
20th
21th
22th
23th
24th
25th
26th
