SkyZone COBRA S - Page 3

AV Jack Pin-out
Headtracker Jack Pin-out
AudioL
AudioR
VIDEO
GND
PPM OUT
GND
Diagram
2
1.Power/Fan
3.CH/BAND/Search
5.Mode
7.3.5mm Head tracker port
9.SD card slot
11.HDMI input
2.System Menu/Headtracker reset
4.Record/Delete
6.USB C port
8.DC PORT(5.5*2.1mm)
10.AV IN/OUTPUT
