OPERATION
37
8. If the leakage current exceeds the high limit setting, but does not exceed the metering
range, the red indicator light will illuminate on the RESET switch and an alarm will
sound. The display will show:
models 2925 and 2935
HI- F A I L MX XXX . X s
X . XX K V A C XX.XX mA
model 2945
W - H i g h MX XXX . X s
X . XX K V A C XX.XX mA
9. If the leakage current does not exceed the low limit setting on model 2925, 2935, and
2945, the red indicator light will illuminate on the RESET switch and an alarm will
sound. The display will show:
models 2925 and 2935
model 2945
LO- L M T M X XXX . X s
X . XX K V A C XX . XX mA
or
W -L o w M X XXX . X s
X . XX K V A C XX . XX mA
10. To stop the alarm, please press the RESET switch once. The alarm will stop and the
display will retain the failure information. If the RESET switch is pressed again, the data
on the display screen will be cleared and the display will indicate the setting data from the
last test. The instrument is now ready for the next test.
11. If the DUT passed the test, the instrument will output a short audible beep tone to
indicate the DUT has passed the test. The display will show:
models 2925 and 2935
P a s s MX XXX . X s
X . XX K V A C XX . XXmA
model 2945
W -P a s s MX XXX . Xs
X . XX K V A C XX . XXmA
The instrument is now ready to perform another test.
