Slaughter 2945 - Measurement and Test Parameters; Insulation Resistance Test Mode Specifications

SPECIFICATIONS
13
Descriptions
Specifications
METERING
Voltmeter (4 digits)
Range : AC 0.00 - 5.00 KV
: DC 0.00 - 6.00 KV
Resolution : .01 KV
Accuracy :  (2  of reading  10 V)
Ammeter (4 digits)
Range : AC 0.10 - 12.00 mA
: DC 0.02 - 5.00 mA
Resolution : 0.01 mA
Accuracy :  (2  of reading  0.02mA)
TIMER DISPLAY
Range : 0.0 - 999.9 seconds
Resolution : 0.1 second
Accuracy :  (0.1  of reading  0.05 seconds)
DISCHARGE TIME
 300 ms
The maximum capacitive load vs. output voltage :
0.20 F ---  1KV
0.10 F ---  2KV
0.06 F ---  3KV
0.050 F ---  4KV
0.040 F ---  5KV
0.015 F ---  6KV
GROUND
CONTINUITY CHECK
Current : DC 0.1 A  0.01A, fixed
Max. ground resistance : 1   0.1, fixed
INSULATION RESISTANCE TEST MODE
Output Voltage
Range:
100 - 1000 Volts DC
Resolution:
10 volt/step
Accuracy:
 (2 of reading  5 volts)
Voltage Display
Range:
0 - 1000 V
Resolution:
10 volt/step
Accuracy:
 (2 of reading  2 counts)
Resistance Display
Range:
1 - 1000 M (4 Digit, Auto Ranging)
Resolution:
500VDC
1000VDC
M
M
M
0.01
1.00 - 40.00
1.00 - 80.00
0.1
35.0 - 999.9
75.0 - 999.9
Accuracy:
 (3 of reading  2 counts)
at test voltage > 500V
 (7 of reading  2 counts)
at test voltage  500V
