SPECIFICATIONS
12
Model 2925, 2935, and 2945
Functional Specifications
Unless otherwise stated, accuracy's are relative to a laboratory standard measurement.
DIELECTRIC WITHSTAND TEST MODE
Descriptions
Specifications
INPUT VOLTAGE
115 / 230V selectable,  10  variation
FREQUENCY
50 / 60 Hz  5%
FUSE
115 VAC, 230VAC -- 3.15A fast acting 250VAC
OUTPUT
Rating AC 0 - 5000V, 2V / step, 12mA
DC 0 - 6000V, 2V / step, 5mA
(DC mode on 2935 and 2945)
Regulation :  (1  of output  5V)
VOLTAGE SETTING
0V - Max output rating, 10 volts/step
Accuracy :  (2  of Setting  5V) (relative to displayed
output)
Can be adjusted during operation via UP and DOWN arrow
keys.
OUTPUT
FREQUENCY
2925 : 50 / 60 Hz selectable
2935 and 2945 : DC and 50 / 60 Hz selectable
WAVE FORM
Sinewave, Distortion : 2  THD
RIPPLE
 5  at 6KVDC / 5mA (2935 and 2945)
DWELL TIME
SETTING
0 and 0.2 - 999.9 seconds, 0.1 second / step
“0” for continuous running
RAMP TIME
SETTING
Model 2925, 2935, and 2945
0 and 0.2 - 999.9 seconds, 0.1 second / step
0 ramp setting = 0.1 seconds fixed ramp
Model 2925
Ramp = 0.1 seconds fixed
FAILURE SETTINGS
AC mode
High limit : 0.10 - 12.00 mA, 0.01 mA / step
Low limit : 0.00, 0.10 - 12.00 mA, 0.01 mA / step (0= OFF)
(2925, 2935, and 2945)
Accuracy :  (2  of setting  0.02 mA)
DC mode
High limit : 0.02 - 5.00 mA, 0.01 mA / step
Low limit : 0.00, 0.02 - 5.00 mA, 0.01 mA / step (0= OFF)
(2925, 2935, and 2945)
Accuracy :  (2  of setting  0.02 mA)
