SLEIPNER MOTOR AS Side-Power Automatic Main Switch - Table of Contents

2
516 9
2 2020
-
DECLARATION OF CONFORMITY
Sleipner Motor AS
P.O. Box 519, Arne Svendsensgt. 6-8
N-1612 Fredrikstad, Norway
Declare that this product with accompanying standard control systems complies with
the essential health and safety requirements according to:
DIRECTIVE 2013/53/EU
DIRECTIVE 2014/30/EU
DIRECTIVE 2014/35/EU
MC_0020
Installation Instructions
Considerations and Precautions................................................ 3
Measurements ......................................................................... 4
Specications ............................................................................ 5
AMS installation ......................................................................... 6
Electrical Specications ............................................................ 7
Wiring Diagram ......................................................................... 8
Service ...................................................................................... 9
Spare Parts ............................................................................ 10
Warranty statement .............................................................. 10
Products
SM901970 | 897612 - Auto-Mainswitch 12V
SM901971 | 897624 - Auto-Mainswitch 24V
Contents
EN
It is the installers responsibility
When installing Side-Power equipment to follow the outlined regulations/ classi cation rules (electrical/ mechanical) according to
international or special national regulations. Instructions in this guide cannot be guaranteed to comply with global electric/ mechanic
regulations/ classi cation rules.
To follow all health and safety laws in accordance with their local outlined regulations/ classi cation rules.
Before installation, it is important that the installer reads this guide to ensure necessary acquaintance with this product.
The recommendations made in this manual are guidelines ONLY, and Sleipner Motor AS (Side-Power) strongly recommend that
before installation, advice is obtained from a naval architect familiar with the particular vessel and regulations/ classi cations.
This manual is intended to support educated/ experienced staff and is therefore not suffi cient in all details for professional
installation. (NB: These instructions are only general instruction. If you are not skilled to do this work, please contact professional
installers for assistance.)
All electrical work must be done by a licensed professional.
Faulty installation of the tunnel, thruster or panel will render all warranty given by Sleipner Motor AS void.
MC_0038
MC_0273
Considerations and Precautions
EN
• Install the automatic main switch as close to the battery(ies) as possible.
• Do not connect the Sleipner automatic main switch with other products than appropriate original Sidepower control panels or other Sidepower control
devices. (NB: Sleipner products are speci cally designed with a separate  fth control cable for the automatic main switch.)
• The automatic main switch must be installed so that it keeps dry at all times.
• The automatic main switch can NOT be  tted in spaces requiring Ignition protected equipment.
• Ensure to use the correct fuse for the main switch depending on the thruster model installed.
IMPORTANT
This manual is to be used in addition to the regular installation manual for the Sidepower thruster. This manual is intended for professionals only.
