Sleipner SE80 - Bow Installation Instructions; Thruster Installation Instructions

2
2687
16 2 0 21
-
SE80 & SE100 & SE120 & SE130 & SE150
DECLARATION OF CONFORMITY
Sleipner Motor AS
P.O. Box 519, Arne Svendsensgt. 6-8
N-1612 Fredrikstad, Norway
Declare that this product with accompanying standard control systems complies with the
essential health and safety requirements according to:
DIRECTIVE 2013/53/EU
DIRECTIVE 2014/30/EU
DIRECTIVE 2014/35/EU
MC_0020
Contents
EN
Bow Installation Instructions
Bow Installation Considerations and Precautions .................... 3
Thruster Measurements ........................................................... 4
Thruster Specications............................................................... 5
Technical Specications ........................................................... 5
Positioning of the tunnel / thruster ............................................ 6
Tunnel Length ............................................................................. 7
Tunnel installation in sail boats .................................................. 8
Water Deflection ......................................................................... 9
Tunnel ends ............................................................................. 10
Tunnel installation ............................................................ 11 - 12
Stern tunnel installation .......................................................... 13
Thruster Installation Instructions
Thruster Installation Considerations and Precautions ........... 14
Gear Leg & Motor Bracket Installation .................................... 15
Propeller Installation ............................................................... 16
Motor Installation .................................................................... 17
Thruster Electrical Installation................................................ 18
Electrical Specications ......................................................... 19
Control Panel Cable Installation ............................................ 20
Visual Wiring Diagram ............................................................. 21
Technical Wiring Diagram ....................................................... 22
Control Panel Installation ....................................................... 23
Pre-delivery Checklist ................................................... 24
Service and Support ...................................................... 25
Product Spare Parts and Additional Resources ............... 25
Warranty statement ...................................................... 25
MC_0031
Bow Installation Considerations and Precautions
EN
• The thruster must NOT be installed in compartments that require ignition proof electric equipment. If necessary, make a separate compartment.
(NB: Ignition Protected systems are tested to be installed in areas with possible explosive gases in accordance with ISO 8846)
• The electro motor will generate some carbon dust so any storage compartments must be separated from the thruster to prevent nearby items
becoming dusty/ dirty. (NB: IP version motors generate dust but are enclosed.)
• When installing the thruster electro motor in small compartments, ensure the compartment is well ventilated to allow for cooling of the electro
motor.
• If the height of the room you are installing the thruster is limited, the thruster can be installed horizontally or at any angle in-between.
- If the electro motor is positioned more than 30 degrees off vertical, it must be supported separately.
- Beware of keeping installation within advised measurements. No part of the propeller or gear house must be outside the tunnel.
• Do not install the thruster in a position where you need to cut a stiffener/ stringer/ support that may jeopardise the hull integrity without checking
with the boat builder this can be done safely.
• The electro motor, components and cables must be mounted so they remain dry at all times.
• We advise painting the gear house and propellers with anti-fouling. (NB: Do not paint the anodes, sealing, rubber fi ttings or propeller shafts)
• Do not  nish the inside of the tunnel with a layer of gel-coat/ topcoat or similar. There is only room for a thin coat of primer and two layers of anti-
fouling between the tunnel and the props.
• Don’t install the electro motor close to easily flammable objects or equipment as it will reach over 100°C before the temperature switch is activated.
• Do not store items close to the thruster motor. Any loose items near the thruster motor is a potential  re hazard and can cause undesired short-
circuiting.
Products
SE150/215T-24V - SE150 Tunnel thruster, 24V
SE150/215T-24 - SE150 Tunnel thruster, 24V
SE130/250T-24V - SE130 Tunnel thruster, 24V
SE130/250T-12V - SE130 Tunnel thruster, 12V
SE120/215T-24 - SE120 Tunnel thruster, 24V
SE120/215T-24V - SE120 Tunnel thruster, 24V
SE100/185T-24V - SE100 Tunnel thruster, 24V
SE100/185T-12V - SE100 Tunnel thruster, 12V
SE80/185T-24V - SE80 Tunnel thruster, 24V
SE80/185T-12V - SE80 Tunnel thruster, 12V
