Sleipner SE80 - Technical Wiring Diagram

22
2687
16 2 0 21
-
SE80 & SE100 & SE120 & SE130 & SE150
MG_0032
Technical Wiring Diagram
EN
Battery
12/ 24 V
+
thruster
motor
c
A1
(B-)
Battery
main switch
Main fuse
D2
red
red
black
black
blue
grey
red
9-way socket
1A (PTC)
Control box
6 1232i
(simplified)
AMP connector
1234
9 8 7 6 5 4 3 2 1
8 5 9 2 4 7 1 3 6
brown
white
blue
grey
red
D1
thruster
solenoid
B+
A2
1
Timer
(Direction)
SIDE-POWER ‘on-off’
control panel
(ON)
2 3 4
blue (STB)
grey (PORT)
red
yellow
black
