Sleipner SM901970 - Page 9

9
519 6
4 2 0 21
-
MG_0325
+
Main
positive
Automatic
Main switch
Control
box
6 1225
black
SIDE-
POWER
M
yellow
5 lead
Sidepower
control cable
Automatic
Main switch
Control
box
6 1225
black
SIDE-
POWER
M
yellow
5 lead
Sidepower
control cable
To more control
stations
Sidepower DUAL
Control panel
8902-A or 8909-A
with yellow output
On thruster
On thruster
Bow
Stern
Yellow
Red
to positive
see comments
Red
to positive
see comments
Main switch with fuse, 12 or 24V version.
(Select fuse size depending on the thruster.)
ON/OFF thruster panel(s).
Thermal switch built into the thruster motor.
Power feed fused to protect the wire.
Negative power feed for the solenoid.
Dual Thruster Wiring
A
A A
B
B
C
C
C
D
D D
E
E E
Technical Wiring Diagram
