Emission values for sound (Two-figure – specifications as per ISO 4871)
Extension cord
If the use of an extension cord
is required, its length and con-
ductor cross-section must be adequate for the
application in order to prevent a voltage drop in
the extension cord, power loss and overheating
of the power tool. Otherwise, the extension
cable and power tool are prone to electrical
danger, and the working efficiency is
decreased.
Recommended dimensions of extension cords
at an operating voltage of 120 V – single-phase
a. c., with only one power tool JCM200Q/
JCM206Q connected:
Intended use of the power tool.
Magnetic base drill for drilling with annular
tools and twist drill bits, reaming, countersin-
king and tapping on materials with surfaces
suitable for magnets in weather-protected
environments using the cutting tools and
accessories recommended by the manufactu-
rer.
Sound emission
JCM206Q JCM200Q
A-weighted emission pressure power level measured at the work-
place L
pA
(re 20 µPa), in decibels 83 83
Measuring uncertainty K
pA
, in decibels 3 3
Measured A-weighted sound power level L
wA
(re 1 pW), in deci-
bels 96 96
Measuring uncertainty K
wA
, in decibels 3 3
C-weighted peak sound pressure level measured at the workplace
L
pCpeak
, in decibels 100 100
Measuring uncertainty K
pCpeak
, in decibels 33
REMARK: The sum of the measured emission value and respective measuring inaccuracy
represents the upper limit of the values that can occur during measuring.
Wear ear protection!
Measured values determined in accordance with the corresponding product standard.
Max. cable length, ft Max. cable length, m
≤ 100 100
–200
200
–300
≤ 30 30
– 60
60
–100
Min. conductor size
(A.W.G.)
Min. conductor
cross-section, mm
2
16 14 12 1.5 2.5 4
WARNING
