Slugger Magforce 06920 - Machine and Spoke Handle Parts List

machine and spoke handle parts list
13
item description part # qty
1 FRAME ASSEMBLY 06936V1 1
2 BALL BEARING UH3045 1
3 FIELD, 120V 06922A 1
FIELD, 220V 06923A
4 ARMATURE ASSEMBLY, 120V 06914 1
ARMATURE ASSEMBLY, 220V 06915
5 M4 X 10 FHSCS UH0410 8
6 QUILL ASSEMBLY 06908 1
7 HELICAL GEAR 06802 1
8 EXTERNAL RETAINING RING UH4016 1
9 OUTPUT PINION ASSEMBLY 06910 1
10 INTERMEDIATE PINION ASSEMBLY 06912 1
11 M5 X 12 DOWEL PIN UH4200 2
12 GEARBOX COVER ASSEMBLY 06944 1
13 M4 X 12 SHCS UH0422 8
14 M4 LOCK WASHER UH2044 8
15 PINION FEED SHAFT 06206 1
16 EXTERNAL RETAINING RING UH4050 1
17 PCB BASE 06328 1
18 PC BOARD, 120V U55006 1
PC BOARD, 220V U55008
19 PCB COVER 06330 1
20 M4 X 20 SHCS UH0434 2
21 POWER CORD ASSEMBLY, 120V 06935 1
POWER CORD ASSEMBLY-AS SPECIFIED, 220V
22 M3 X 5 CRPHMS UH0300 1
23 M3 LOCK WASHER UH2035 1
24 MAGNET ASSEMBLY, 120V 06907 1
MAGNET ASSEMBLY, 220V 06905
25 SAFETY STRAP LINK U11004 1
26 SAFETY STRAP U11005 1
27 M5 X 20 SHCS UH0542 4
28 M5 LOCK WASHER UH2054 4
29 COOLANT BOTTLE ASSEMBLY 06934 1
30 SPOKE HANDLE ASSEMBLY 06315 1
31 MOTOR BRUSH 04549 2
32 BRUSH CAP 04552 2
33 SPECIFY 2 OR 4 BUTTON AND VOLTAGE CALL 1
34 #2 X 3/16" DRIVE SCREW UH1002 2
35 MAGNET SWITCH ASSEMBLY 06511 1
36 GUARD ASSEMBLY 06940 1
MACHINE PARTS LIST
item description part # qty
1 HUB U12004 1
2 SPOKE HANDLE U12200 3
3 M6 X 30 SHCS (NOT SHOWN) UH0654 1
4 1/4" PUSH NUT (NOT SHOWN) UH4600 1
SPOKE HANDLE ASSEMBLY PARTS LIST
