such as a CD players line output or a 3.5mm stereo mini-jack
connection from your PC’s standard soundcard.
* Note: You can connect up to three different devices to the
three physical connector possibilities simultaneously. The
input selector on the front panel allows selection of the
desired input!
Analog output connectors
The M-Patch 2 features two (2) pairs
(L&R) of XLR balanced analog output
connectors on the rear panel. These are
labeled “1” & “2”.
Connect these outputs to your
destination device (active monitors,
digital recorder, or wherever you need
the attenuated output signal sent).
* Note: It is possible to activate or deactivate each desired
output pair via the ‘output selector switches’ on the front
panel. It is possible to have both 1&2 outputs active at the
same time. This is very useful when connecting the outputs to
a recording device and a monitoring device simultaneously!
