3.Adjust the mortise direction
According to your need to adjust the mortise direction
Latch shifting plate
Latch
Not allow to disassemble the face plate
(1) Pull the Latch shifing plate to another side
(2) Push the latch into the mortise and turn 180 degree
4.Caution before installation
(1)
when installation, avoid
to damage the lock.
Do not put strong force
(2)
installation tools.
Use correct (3)
protect your eyes
when drilling holes.
Wear glass to
(4)
the door to avoid damage the door
surface.
Drilling the holes on both side of
5.Installation
Installation steps:
As Figure 1:
(1) Divide the Back Lock into Battery
cover and Back panel.
As Figure 2:
(1) Fix the mortise with 2 screws.
As Figure 3:
(1) Fix the two connecting pillars on the
front panel.
Battery cover
Back
lock
Figure 1 Figure 2 Figure 3
Front lock
Connecting
pillar
3
4
2
1
