General Charging Warnings
WARNING: Failure to exercise caution while using this product and comply with the following warnings could result in product malfunction, electrical issues, excessive heat,
FIRE, and ultimately injury and property damage.
NEVER LEAVE CHARGING BATTERIES UNATTENDED DURING USE.
NEVER CHARGE BATTERIES OVERNIGHT.
Never attempt to charge dead, damaged or wet battery packs.
Never attempt to charge a battery pack containing different types of batteries.
Never allow children under 14 years of age to charge battery packs.
Never charge batteries in extremely hot or cold places or place in direct sunlight.
Never charge a battery if the cable has been pinched or shorted.
Never connect the charger if the power cable has been pinched or shorted.
Never connect the charger to an automobile 12V battery while the vehicle is running.
Never attempt to dismantle the charger or use a damaged charger.
Never attach your charger to both an AC and a DC power source at the same time.
Never connect the input jack (DC input) to AC power.
Always use only rechargeable batteries designed for use with this type of charger in the correct programming mode.
Always inspect the battery before charging.
Always keep the battery away from any material that could be affected by heat.
Always monitor the charging area and have a fire extinguisher available at all times.
Always end the charging process if the battery becomes hot to the touch or starts to change form (swell) during the charge process.
Always connect the charge cable to the charger first, then connect the battery to avoid short circuit between the charge leads. Reverse the sequence when disconnecting.
Always connect the positive red leads (+) and negative black leads () correctly.
Always disconnect the battery after charging, and let the charger cool between charges.
Always charge in a well-ventilated area.
Always terminate all processes and contact Horizon Hobby if the product malfunctions.
Charge only rechargeable batteries. Charging non-rechargeable batteries may cause the batteries to burst, resulting in injury to persons and/or damage to property.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
For indoor use, do not expose to rain or moisture.
Never impact or alter the batteries.
WARNING: Never leave charger unattended, exceed maximum charge rate, charge with non-approved batteries or charge batteries in the wrong mode. Failure to comply may
result in excessive heat, fire and serious injury.
CAUTION: Always ensure the battery you are charging meets the specifications of this charger and that the charger settings are correct. Not doing so can result in excessive
heat and other related product malfunctions, which can lead to user injury or property damage. Please contact Horizon Hobby or an authorized retailer with compatibility questions.
Specifications
Output Port Connector
IC3®/IC5® selectable (EC3™/EC5™
ompatible)
Balance Current 1.5A/cell
Input Voltage 100–240V AC Balance Cells 1–6S
Charge Current 0.1 – 20.0A
Supported Battery Types* (cell count)
LiFe/LiIon/LiPo/LiHv (1–6S)
Discharge Current 0.1 – 1.5A NiMH/Cd (1–16S)
USB Output 5V / 2A Pb (1–12S)
Max. Charge Power 2 x 200W Display 3” 320 × 240 IPS LCD
Max. Discharge Power 10W Operating Temperature 0–40°C (32–104°F)
* Spektrum G2 Smart chargers are compatible with all Spektrum G1 Smart batteries.
Diagram
