Smart temp SMT?770 - Specifications

35|Page


Specifications

InputVoltage 24VAC50/60Htz+/‐15%.
Currentconsumption 15mAStandby(Backlightoff)
 70mAAllrelaysandbacklighton.
Relayrating 24VAC@1Ampmaximumperrelay.
OperatingTemperature 0‐50C(32to122F).
OperatingRH 0‐95%(noncondensing).
StorageTemperature 0‐65C(32to150F).
Size 113x
103x23mm.
DisplaySize 74x55mm.
TemperatureSensor(s) 10KNTCtype3.
Memorytype Nonvolatile–Settingsdonotrequirebatterybackup.
Accuracy +/‐0.3degC@25C.(77F)
StageDelays Minimumtemperaturechange+timemethod.
Maximumstagescontrolled 2cool&3heat(Installerselectable)

FanSpeedscontrolled 1or3(Installerselectable)
TimedupstageDelay 5~90minutes(installeradjustable).
Anti‐cycleDelay Offor4minutes.
Maximumhourlycycles Unlimited,30,10or6.(Installerset)

