Maintenance
Overall vehicle
15
Introduction of smart fortwo electric drive (3rd Generation) • Model Series 451
Maintenance items at front
The following maintenance items are accessible
via the front service flap:
1 Brake fluid reservoir
2 Windshield washer fluid reservoir
3 Coolant expansion reservoir
4 Lamp unit for bulb replacement
P00.20-2678-00
High-voltage battery desiccant cartridge
The desiccant cartridge is located on the under-
side of the high-voltage battery under the
connection for the high-voltage lines on the right
in the direction of travel:
1 Desiccant cartridge
G5 High-voltage battery
P54.10-3719-00
