Body
82
Design
Introduction of smart fortwo electric drive (3rd Generation) • Model Series 451
Underfloor
Reinforcements
The reinforcements for the high-voltage battery
are located in the area of the underfloor.
Underfloor paneling
A continuous underfloor panel made of plastic is
installed in the front area from the bumper up to
the high-voltage battery. This has the effect, for
example, of significantly reducing the ingress of
dirt and corrosive materials.
P60.00-2945-00
1 High-voltage battery supporting strut
2 Reinforcement for protection against side
crashes
