SMART LightRaise - Page 31

31 1018488 Rev 06
1. Turn the switch ‘ON’.
2. To test the alignment tool, press the ‘front side’ against the markerboard surface. The ‘status LED’ should
turn green.
Alignment Tool
Click the ‘forward arrow’ button to go to the trace page
status LED
front side
back side
top side
ON/OFF switch
battery door
handle
