Helpful hints 10!9
Bulbs
How to change the taillight
Each taillight consists of:
! Bulb, turn signal 12 V 21 W
! Tail lamp/brake light 12 V 21 W
! Rear fog lamp (left) 12 V 21 W
! Backup lamp (right) 12 V 21 W
! Open the rear luggage compartment.
! Unscrew the retaining screw at the
point shown.
! Press the taillight sideways out of its
fixture.
! Turn the holder anticlockwise to
remove it from the housing.
>The plug connection remains in the
holder.
! Turn the bulb anticlockwise and take it
out of the holder.
>Note!
Installation occurs in reverse order.
Changing the third brake light
! Loosen and remove the retaining
screws (A).
! Remove the lens (B).
! Remove the reflectors (C).
! Remove the faulty bulb (D) from its
holder.
>Note!
Installation occurs in reverse order.
