PARTS & ASSEMBLY
Parts
After Taking the Unit Out of the Box
Wipe down the SMART 5-IN-1 exterior with a clean, non-abrasive cloth or sponge.
Thoroughly wash Blending Chamber, Aluminium Cylinder, Cylinder Cage and Lid in warm,
sudsy water and thoroughly dry. DO NOT put the Base in water.
Assembly
1. After drying, rmly attach Blending Chamber to Base by placing the Blending Chamber on
top of Base. If Blending Chamber is attached properly, it will be aligned with Base so that the
Spout is over the Drip Tray.
2. Next, put Mixing Mechanism inside of Aluminium Cylinder and put Aluminium Cylinder
inside of Cylinder Cage. Then place Cylinder assembly inside of Blending Chamber.
1. 2.
Blending Chamber
Drip Tray
Base
Blending Chamber Lid
Spout
Non-Stick
Aluminum Cylinder
Cylinder Cage
Mixing Mechanism
