Engine mount
Engine M132
41
Introduction of the smart fortwo, Model Series 451
Engine mount/torque support
The engine with transmission is mounted on two
mounts and a torque support. They were designed to
dampen inherent engine vibrations. They also consid-
erably reduce the rocking of the drive assemblies
during load changes. The reduction in vibrations and
in the tendency to rock provides a higher level of
driving safety and ride comfort.
P22.10-2299-00
Engine mount, transmission mount and torque support
1 Frame-type integral support
2 Engine mount
3 Transmission mount
4 Torque support
