7
Attaching the Eye gaze unit
To attach the Eye gaze unit you need to:
1. Lift the eye gaze stand to 90 degrees
2. Connect the Eye gaze unit to the bottom
of your Grid Pad. The pins will help guide
the positioning of the unit. Make sure the
unit is in the centre of the device and the
camera points outwards.
3. Use a socket screwdriver to tighten the
two screws on the back of the Eye gaze
unit to attach it firmly to your Grid Pad.
