USER’S MANUAL PAGE 13SBC-125
OVER-TEMP /
Output current reduces to 0 when
temperature in charger is too high
(exceeds 269.6˚/132˚). After cooling
down for a few minutes, the charger
will automatically begin charging with
6<>2A CHARGE/MAINTAIN rate if a
battery is connected, and the battery
type has memory
function and is the same as before.
BAD-BATT /
The battery cannot store electric
charge (dead battery) after 3-minute
analysis (ANALYSING-2 Display).
BATTERY CHARGING TIMES
Ah - Ampere Hours CCA - Cold Cranking Amps
RC - Reserve Capacity MO - Maintain Only
Use the following table to determine the time it will take to bring a battery to
full charge.
BATTERY SIZE/RATING(6V/12V)
CHARGE
RATE/TIME
6A<>2A
SMALL BATTERIES 6-12 Ah
1½ - 2½ h
Motorcycle, garden tractor, etc. 12-32 Ah 2½ - 7½ h
CARS/
TRUCKS
200-315 CCA 40-60 RC 7½ - 9½ h
315-550 CCA 60-85 RC 9½ - 13½ h
550-1000 CCA 85-190 RC MO
