USER’S MANUAL PAGE 12SBC-125
125A ENGINE START (press RATE SELECTION button three times to
enter based on OFF mode) – Provides additional amps for cranking an
engine with a weak or run-down battery. Always use in combination with a
battery for ENGINE START mode. Must NOT touch or disconnect clamps
when ENGINE START mode works, otherwise there may be serious injuries
to people or property.
NOTE:
1. When entering CHARGE/MAINTAIN or BOOST, the charger will
automatically detect 6V or 12V in ten seconds (display shows ON, then
ANALYSING-1). After BATT-06V or BATT-12V is showed on digital
screen, CHARGING will show (charging has started).
2. If RATE SELECTION button is not pressed in the starting 10 minutes,
the charger will automatically begin charging with 6V/12V STD and
6<>2A CHARGE/MAINTAIN if a battery is connected.
ERROR SITUATIONS
Digital display Warning LED
indicator
Explanation
REVERSED
REVERSE
CONNECTION
LED lit
The connections are reversed.
NO-CONNECT /
No battery connected / battery volt-
age is lower than 1 volt (dead battery)
/ red and black clamps are connected
together.
40<>15A BOOST (press RATE SELECTION button twice to enter based on
OFF mode) – This setting can be used for a quick boost, prior to using the
engine start setting. When Boost mode ends, VOLTAGE LED will
illuminate and display screen will show battery voltage, and meanwhile
BOOST LED will ash. Boost does NOT make battery fully charged. You
can select CHARGE/MAINTAIN mode by pressing RATE SELECTION
button to continue to charge the battery.
