USER’S MANUAL PAGE 15TECH-5000P
SUPPLY TO 12V APPLIANCES
The TECH-5000P Power Bank can run/charge 12VDC appliances
that draw 10 amps or less. Two Options as follows:
USING THE 12V ADAPTER
Connect the TECH-5000P Power Bank to a 12V appliance
with the included 12V adapter accessory. You don’t need to
press the power button as the Power Bank output is ALWAYS
activated. When battery voltage of TECH-5000P Power Bank
is too low, 12V appliances will stop running/charging.
EC5
Plug
12 Volt
Adapter
TECH-5000P
Power Bank
Pull rubber tab to open
ENGINE START
socket
See detailed diagram below
