Smartech TECH-5000P - Using the Air Pump; Connect Air Hose and Power

USER’S MANUAL PAGE 29TECH-5000P
3. Connect air pump to power (choose either of the 3 options
mentioned in previous section).
USING THE AIR PUMP
1. Connect the air hose to the air pump by screwing the hose into
the end of the Air Pump.
2. Connect the other end of the air hose to the valve stem of the
item you are inating. Adaptor is needed before inating sport
balls including soccer, basketballs and footballs.
Air
Hose
Screw air hose
to air pump here
Power
Button
Air
Pump
Vehicle Tires
Other Inflatibles
Requiring Adapter Pins
Adapter Pins (if needed)
Wide
Adaptor
Narrow
Adaptor
Ball Pin
Adaptor
See detailed diagram below
NOTE: When inating items of 10 PSI or less, inate in short
bursts and check after each burst by feel or with a calibrated
measuring device to determine accurate pressure. Pressure
required for most sports balls is too low for accurate reading
on tool gauge.
