5
The unit should be stored in an area that will afford some protection from the elements to
insure that it retains its finish
. DO NOT STORE NEAR OPEN CHEMICALS
• To reapply the filter bag, first turn it right side out. Next place the filter bag frame onto
the bottom lid being sure that the bag frame seats fully into the channel. Press down
on all corners to ensure fit. Check the seat of the filter onto the bottom lid (see Figure 7)
FIGURE 7
FIGURE 8
FIGURE 9
FIGURE 10
• Pick up the bottom lid and turn it over so the bag hangs below it (see Figure 8). Place
the bottom lid back into the cleaner being careful to feed the filter bag into the body of
t he cleaner. MAKE SURE ALL FILTER MATERIAL IS INSIDE THE CLEANER
OTHERWISE THE LID WILL NOT CLOSE AND LATCH PROPERLY.
• Once the bottom lid is seated press it firmly into the cleaner. Gently pull on the bottom
lid to insure that it is properly locked in. The lid is now installed.
CABLE MAINTENANCE
UNCOILING THE CABLE
In the course of using your Direct Command Plus, the cord may begin to coil. Excessive
coiling can lead to improper cleaning coverage of your pool.
• To uncoil the cord, it is best that the cable is wet.
• Place the cleaner on the ground as shown in Figure 9.
• Be sure to use a clear area that will allow the cord to stretch out in a straight line.
• Pull the cable so it is off the ground
• Using your fingers, roll the cable in the opposite direction that it is coiled in.
STORING THE CABLE
• Loosely loop the cable as shown in Figure 10.
• Hold the cord close to the cleaner.
• Make a roughly two foot loop with
the cord as shown.
• When making loop, roll the cable
slightly in a counter clockwise
manner to maintain form.
DO NOT WRAP THE CORD
TIGHTLY AROUND OBJECTS.
STORAGE
WINTER
SUMMER
If temperatures will regularly be below 45 degrees Fahrenheit or 5 degrees Celsius, the
cleaner and power supply should be stored indoors.
