6.2) Device Overview
1. Micro USB port
2. Power switch
3. Buzzer
4. LCD touch screen
5. LED light source
6. Test probe
7. Probe tip protector
8. Battery Percentage
9. USB type A Output Port
10. Lightning Input Port
11. Micro USB Input port
6. DEVICE ACCESSORIES AND OVERVIEW
8
1
2
3
5
7
6
9
11
10
IN2
IN1
OUT
4
7
