SMASH 16 - Technical Specifications

71
SMASH 16
Specifications are subject to change without notice.
Dry weigth 4,5 kg.
MASS
Weigth with bar and chain 5,3 kg.
Fuel tank 310 cm
3
VOLUME
Chain oil tank 210 cm
3
Guide bar 16”/40 cm.
CUTTING
LENGTH
Usable cutting length 38 cm.
Chain pitch 9,525 mm / 0,375”
Chain gauge 1,27 mm / 0,050”
Chain type
3/8” low profile 0.050”
57 links
CHAIN
Guide bar type Sprocket nose
SPROCKET Teeths number and chaín pitch 6 X 9,525 mm.
Displacement
37,2 cm
3
Engine maximum power (ISO 7293) 1,2 kw.
Recommended maximum speed with bar and
chain
10.000 min
-1

Recommended speed at idle ≤3.000 min
-1

Specific fuel comsumption at engine maximum
power
560 g/kWh
Sound power level (2000/14/EC) 110 dB (A)
Emisión sound pressure level at the operator
position (ISO 22868)
100 dB (A)
Vibration level (ISO 22867) 8,010 m/s
2
Carburator Diaphragm type
ENGINE
Oil feeding system Automatic pump with regulator
TECHNICAL SPECIFICATIONS
