■Details of the Parameter Data
•SI unit (ITV)

Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:01
Monitor short circuit (power)
Enum0800
0 = Disable
1 = Enable
40x1:0
ITV1 – Configuration
UNSIGNED8
6
40x1:01
Hold/Clear
Enum081F
0 = Pressure clear
1 = Pressure hold
40x1:02
Gain
UNSIGNED8
0 to 15
40x1:03
Sensitivity
UNSIGNED8
0 to 7
40x1:04
Minimum pressure
UNSIGNED16
0 to 3686
40x1:05
Maximum pressure
UNSIGNED16
410 to 4914
40x1:06
Notification setting of the accumulated
energizing time
UNSIGNED32
0 to 429467295
40x2:0
ITV2 – Configuration
See ITV1 - Configuration
40x3:0
ITV3 – Configuration
40x4:0
ITV4 – Configuration
: If the “SI unit data size setting switch (ITV module)” (page 22) is set to “No ITV module”, the SI unit (ITV) objects will not be
displayed.
Note: x = Unit No.
