Intelligent Valve Positioner IP6000 Series User’s Manual
63
4. Technical data
Shell material
Aluminum
Set-point signal
4-20mA DC, no-load voltage: 15-24V DC
Minimum working current
3.8mA
Input resistance
120Ω
Ambient temperature
Normal version:-20°C ~ +70°C
Optional version:-40°C ~ +70°C
Highest explosion proof temp for T4 area is +60°C
Highest explosion proof temp for T6 area is +40°C
Gas source requirement
ISO 8573-1
 Solid particle size and density Class 3
 Dew point Class 3
 Oil content Class 3
Vibration resistance
0.15mm,10Hz-60Hz,20 cycle/axis
20m/ s²,60Hz-500Hz,20 cycle/axis
Recommended range for control valve≤ 20 m/s²，no resonance
peak
Supply pressure
0.14~0.7MPa
Flow
 Input air
2 bar 4.8 Nm³/h
4 bar 8.0 Nm³/h
6 bar 11.2 Nm³/h
 Exhaust air(Safe)
2 bar 5.9 Nm³/h
4 bar 9.8 Nm³/h
6 bar 13.7 Nm³/h
 Exhaust air (Freeze)
2 bar 6.6 Nm³/h
4 bar 11.1 Nm³/h
6 bar 15.6 Nm³/h
Steady state air consumption
≤0.4 L/min
Basic error
≤1.0%
Hysteresis error
≤1.0%
Electrical connection
M20×1.5
Pneumatic connection
G1/4
Weight
2.0 kg
Protection class
IP66
Explosion-proof class
Ex ia IIC T4/T6 Ga
