Instructions for the user
10.3 Removing the door
Open the door completely.
Insert a pin into the hole in the
hinge. Repeat for both hinges.
Grasp the door on both sides
with both hands, lift it forming an
angle of around 30° and remove it.
To reassemble the door, put the
hinges in the relevant slots in the
oven, making sure that grooved
sections C are resting completely
at the base of the slots. Lower
the door and once it is in place
remove the pins from the holes in
the hinges.
10.4 Removing the door seal (not on pyrolitic models)
To permit thorough cleaning of the oven, the door seal may be
removed.
There are fasteners on all four sides to attach it to the edge of
the oven. Pull the edges of the seal outwards to detach the
fasteners. The seal must be replaced when it loses elasticity
and hardens.
