35
Instructions for the installer
Connect to the appliance using a BS 669 compliant bayonet
hose. The connector, at the back of the appliance, has a 1/2”
BSP external thread. Apply insulating material to the thread of
the gas pipe connector 4 and then tighten the adapter 3 to it as
indicated in the figure. Screw the assembly to the moveable
connector 1 of the appliance, placing the seal 2 between them.
