Installation
52
5.2 Cable replacement
1. Unscrew the fastening screws 2 of the
terminal board cover.
2. Slide the tabs 1 of the terminal board
cover out of the grooves;
3. Loosen the screw of the cable retention
bracket in the right lower part of the oven
back 3;
4. Make sure that the cables (for the oven
or any hob) follow the best route in order
to avoid any contact with the appliance.
5.3 Positioning
Power voltage
Danger of electrocution
• Disconnect the main power supply.
Heavy appliance
Danger of crush injuries
• Place the appliance into the piece of
furniture with the aid of a second person.
Pressure on the open door
Risk of damages to the appliance
• Never use the oven door to lever the
appliance into place when fitting.
• Avoid exerting too much pressure on the
oven door when open.
Heat production during appliance
operation
Risk of fire
• Check that the piece of furniture material
is heat resistant.
• Check that the piece of furniture has the
required slots.
