User instructions
51
LOADING THE UPPER BASKET
Load plates facing forward; cups, bowls etc. must always be facing
downwards. The left-hand side of the basket can be loaded with two
layers of cups and glasses. The centre can be filled with plates and side-
plates, fitted upright into the supports provided.
Loading examples:
ADJUSTING THE UPPER BASKET
The upper basket can be adjusted in
two positions
, according to the
user’s needs and according to the height of the dishes in the lower
basket.
Proceed as follows:
•
turn the retainer
E
on both runners, right and left, through
90°
;
•
remove the basket;
•
lift the basket and fit the smaller pairs of wheels in the runners;
•
return the retainers
E
to their original position.
