Smeg FQ70GBE - Page 24

Use
57
EN
Removing the ice bin
1. Lift and remove the ice bin.
2. Remove it in the direction of the arrow.
Reinstalling the ice bin
1. Insert it in the direction of the arrow.
2. Place the pin (1) into the support (2) and
insert the guide (3) into the stop (4).
3
4
12
