INSTALLATION INSTRUCTIONS:
Thehoodissuppliedwithalltheaccessoriesnecessaryfor
itsinstallation.Theminimumdistancebetweenthelower
surfaceofthehoodandthehobmustbeatleast750mm
for gas hobs and 650mm for electric hobs  (Fig. 1 ). If
themotorinletisequippedwithanon-returnvalvefor
fumes,makesureitcanopenandclosefreely.
Foreasyinstallationitisrecommendedtofollowtheprocedures
describedbelow:
1)Thehoodmustbecentredwithrespecttothehobsurface.
2)There are differentinstallation procedures depending on
thehoodmodel.Chooseoneofthefollowingxingsystems
(Fig.2):
a) 2 levelling hooks that fasten on with the supplied
expansionplugs
b) Rearlevellingbracketthatfastensonwiththesupplied
expansionplugs
c) Levellinganchorsonmotorboxthatfastenonwiththe
suppliedexpansionplugs
d) For island models refer to the special installation
attachment.
N.B.:Fixingsystemsa)andb)tontothebackofthehood
intheholesL1(Fig.4).
3)Removethegreaseltersandpositionthehoodonthewall
andmarkthereferencepositionfortheholestoanchorthe
relativexingsystem.
4)Drillthe2holespreviouslymarkedafterremovingthehood
fromthewall
5)Anchor the xing system to the wall by tightening the
expansionplug
6)MarkholesL2onthewalltosecuretheplugssafelyinthe
holes.(plugssupplied)
7)Hang the hood on the xing system (g. 2) and level it
usingtheadjustmentscrews(g.2).
8)Securelyxthehoodbyfullytighteningthetwoexpansion
screwsoftheholesL2
AIRCONNECTIONSYSTEMS:
EXTRACTION version:  Connect the fume expulsion duct
(insidediameter150mm.)totheexhaustofthemotorinlet.
IftheexpulsionductisD.120mm,usethespecialreduction
ange (F) supplied.  The expulsion duct must not have a
diameteroflessthan120mm.
Notethat ifthehoodissuppliedwithanactivecarbon
lter,thismustberemoved(seepage8)
