3. INSTALLATION
WARNING!
Refer to Safety chapters before
installation.
For detailed installation information, see the
installation instruction supplied with the
appliance.
Valid only for Germany: Before installation,
refer to the chapter "Rückschlagventil" in the
German user manual.
4. PRODUCT DESCRIPTION
6
5
9
10
11
78
12
13
3
4
1 2
1
Worktop
2
Ceiling spray arm
3
Upper spray arm
4
Lower spray arm
5
Filters
6
Rating plate
7
Salt container
8
Air vent
9
Rinse aid dispenser
10
Detergent dispenser
11
Lower basket
12
Upper basket
13
Cutlery drawer
The graphic is a general overview.
For more details, refer to other chapters
or documents provided with the
appliance.
