4. DESCRIPTION OF CONTROLS
4.1 Control zone
All the hob controls are grouped together on the front panel.
CONTROL ZONE
4-burner hob
5-burner hob
KNOB DESCRIPTION
To light the flame, press the knob and turn it anti-
clockwise to between the maximum and the
minimum flame symbol . To adjust the flame, turn
the knob to the area between the maximum and
minimum settings . To turn off the burner, return the
knob to position .
ARRANGEMENT OF BURNERS AND DESCRIPTION OF SYMBOLS
5-burner hob
Front left
Burner
Central external
Burner
Front right
Burner
Rear left
Burner
Central internal
Burner
Rear right
Burner
4-burner hob
Left burner
Rear central
Burner
Right burner
Front central
Burner
