Instructions for the installer
87
380 - 415 V 3N~ five-core 5 x 1,5 mm² H05V2V2-F
380 - 415 V 2N~ four-core 4 x 2,5 mm² H05V2V2-F
220 - 240 V 1N~ three-core 3 x 4 mm² H05V2V2-F
Terminals 4 and 5 must be connected at all times.
10.2 Cable replacement
Should the supply cable need replacing,
remove the back guard by unscrewing the
screws to gain access to the terminal.
Make sure that the cables (for the oven or any
hob) follow the best route in order to avoid any
contact with the oven.
WARNING: The tightening torque of the screws of the terminal supply wires
must be 1.5 - 2 Nm.
