26 - DESCRIPTION 91477A677/A
DESCRIPTION
General description
*Power levels are approximate and may vary according to the pan used or the settings made.
Control panel
1 Cooking zones selection area
2 Control lock button
3 ON/OFF button
4 Increase / decrease button
Advantages of induction cooking
Zone Dimensions
H x L (mm)
Minimum pan
dimensions (mm)
Minimum pan
dimensions (mm)
Max. power draw
(W)*
Power draw in
booster function
(W) *
1-2-3-4 180 x 180 Ø110 Ø180 1500 2000
1+2 (bridge) 180 x 375 Ø160 180 x 375 3000 -
3+4 (bridge) 180 x 375 Ø160 180 x 375 3000 -
The appliance is equipped with an
induction generator for each cooking
zone. Each generator located under the
glass ceramic cooking surface creates
an electromagnetic field which induces
a thermal current in the base of the pan.
This means the heat is no longer
transmitted from the hob to the pan but
created directly inside the pan by the
inductive current.
