Installation
16
DRAIN CONNECTION
Insert the
dishwasher’s drain
hose into a drain pipe
having a diameter of
at least 4 cm
, or
alternatively, place it
inside the kitchen sink
using the plastic
support provided,
taking care not to
crush or excessively
bend the hose.
It is important to p
revent the hose from coming
loose and falling. For this purpose, the plastic
support is equipped with a hole for tying it to the
wall or water tap.
The free end should be
positioned at a height of between 30 and 100
cm, and should never be submerged in wat
er.
If a horizontal drain extension hose is used (for
a maximum 3 m), the drain hose can be placed
at a maximum height of.
85 cm
from the ground.
Class of protection against moisture: IPX0
