Installation
83
EN
B - Class 2 subclass 1
(Built-in appliance)
C - Class 2 subclass 1
(Built-in appliance)
Assembling the upstand
The upstand must always be positioned and
secured correctly on the appliance.
1. Loosen the 3 screws on the back of the
top (A) and unscrew the 2 screws (B) on
the side part of the upstand.
2. Place the upstand on the top. Align the
3 bottom slots of the upstand with the
3 screws on the back of the top that
were previously loosened.
3. Tighten the 3 screws on the back of the
hob (A) and tighten the 2 screws under
the top (B) to secure the upstand.
The appliance must be installed by
a qualified technician and
according to the regulations in
force.
The upstand provided is an
integral part of the product; it must
be fastened to the appliance prior
to installation.
