Installation
102
Burner and nozzle specifications tables
1 Natural gas G20 AUX SR R UR2
Rated heating capacity (kW) 1.0 1.8 2.9 4.2
Nozzle diameter (1/100 mm) 72 97 115 145
Pre-chamber (printed on nozzle) (X) (Z) (H9) (F3)
Reduced flow rate (W) 400 500 800 1300
2 Natural gas G20 AUX SR R UR2
Rated heating capacity (kW) 1.1 1.8 2.9 4.2
Nozzle diameter (1/100 mm) 72 94 110 145
Pre-chamber (printed on nozzle) (X) (Z) (H8) (H3)
Reduced flow rate (W) 400 500 800 1300
3 Natural gas G25 AUX SR R UR2
Rated heating capacity (kW) 1.0 1.8 2.9 4.2
Nozzle diameter (1/100 mm) 72 94 121 143
Pre-chamber (printed on nozzle) (F1) (Y) (F2) (F2)
Reduced flow rate (W) 400 500 800 1200
4 Natural gas G25.1 AUX SR R UR2
Rated heating capacity (kW) 1.1 1.8 3.0 4.1
Nozzle diameter (1/100 mm) 77 100 134 152
Pre-chamber (printed on nozzle) (F1) (Y) (F3) (F3)
Reduced flow rate (W) 400 500 800 1200
5 Natural gas G25 AUX SR R UR2
Rated heating capacity (kW) 1.0 1.8 2.9 3.9
Nozzle diameter (1/100 mm) 77 100 134 165
Pre-chamber (printed on nozzle) (F1) (Y) (F3) (H3)
Reduced flow rate (W) 400 500 800 1200
6 Natural gas G2.350 AUX SR R UR2
Rated heating capacity (kW) 1.0 1.75 2.9 3.7
Nozzle diameter (1/100 mm) 94 120 165 190
Pre-chamber (printed on nozzle) (Y) (Y) (F3) (F3)
Reduced flow rate (W) 400 500 800 1200
