Installation
41
EN
Positioning and levelling
Properly level the appliance on the floor to
ensure better stability.
• After making the electrical and/or gas
connections, screw or unscrew the
bottom part of the foot until the appliance
is stable and level on the floor.
Assembling the skirt
The backguard must always be positioned
and secured correctly on the appliance.
1. Loosen the 6 screws on the back of the
top (A) and unscrew the 2 screws (B) on
the side part of the backguard.
2. Place the backguard on the top. Align
the 6 bottom slots of the backguard with
the 6 screws on the back of the top that
were previously loosened.
3. Tighten the 6 screws on the back of the
hob (A) and tighten the 2 screws under
the top (B) to secure the backguard.
Heavy appliance
Risk of damage to the appliance
• Insert the front feet first and then the rear
ones.
The backguard provided is an
integral part of the product; it must
be fastened to the appliance prior
to installation.
