Installation
42
Mounting the toe skirt
The toe skirt must always be positioned and
secured correctly on the appliance.
1. Open the storage compartment.
2. Place the toe skirt in the front bottom part
of the appliance.
3. Screw the four side screws to fasten the
toe skirt to the appliance.
4. Cover the holes of the toe skirt with the
plugs provided.
Wall fixing
1. Turn the screw placed behind the
cooktop near the gas connection.
2. Attach the chain to the cooker with the
screw just removed.
3. Stretch it out horizontally so that the other
end of the chain touches the wall.
The toe skirt provided is an integral
part of the product; it must be
fastened to the appliance prior to
installation.
