BURNERS
Technical specifications for burners referring to appliance model:
MODEL BURNERS
TOTAL
FLOW RATE
SEMIRAPID AUXILIARY RAPID BROILER OVEN
Ø 62 mm
Ø 2 7/16”
Ø 47 mm
Ø 1 27/32”
Ø 77 mm
Ø 3”
nr. (BTU/HR) nr. (BTU/HR) nr. (BTU/HR) nr. nr. BTU/HR
CU322
1 (5900) 1 (3700) 1 (3700) 13300
CU325
2 (5900) 1 (3700) 1 (3700) 19200
CU402
3 (5900) 1 (3700) 1 (5200) 26600
CU403
3 (5900) 1 (3700) 21400
CU423
1 (5900) 1 (3700) 1 (6700) 16300
CU434
1 (5900) 1 (3700) 1 (6700) 1 (3700) 20000
FO300
1 (3700) 3700
