Smith 88 - Repair Parts

29
INSTALLATION AND OPERATING INSTRUCTIONS
Gas Valve - Nat-Stdg 88-177 VR8200 50581
Gas Valve - Nat-Stdg 206-288 VR8300 50587
Gas Valve - Nat-Sprk 206-288 VR8304 50589
Gas Valve - Nat-Sprk 88-177 VR8204 50583
Gas Valve - LP-Stdg 88-177 VR8200 50582
Gas Valve - LP-Stdg 206-288 VR8300 50588
Gas Valve - LP-Sprk 206-288 VR8304 50590
Gas Valve - LP-Sprk 88-177 VR8204 50584
Pilot Assembly Nat-Stdg 5CH 50248
Pilot Assembly Nat-Sprk Q348 50558
Pilot Assembly LP-Stdg 5CH 50249
Pilot Assembly LP-Sprk Q348 51814
Gas Manifold 118 50264
Gas Manifold 88 50265
Gas Manifold 177 50266
20 Gas Manifold 147 50267
Gas Manifold 236 50268
Gas Manifold 206 50269
Gas Manifold 288 50270
Flue Collector 118 50281
Flue Collector 88 50282
Flue Collector 177 50283
21 Flue Collector 147 50284
Flue Collector 236 50285
Flue Collector 206 50286
Flue Collector 288 50287
Draft Hood 88/118 50252
Draft Hood 147/177 50254
Draft Hood 206/236 50256
Draft Hood 288 50257
23 Insulation Board 7956
Block Assembly 88/118 90684
Block Assembly 147/177 90685
Block Assembly 206/236 90686
Block Assembly 288 90687
Base Front Panel 88/118 50324
Base Front Panel 147/177 50325
Base Front Panel 206/236 50326
Base Front Panel 288 50327
Base Rear Panel 88/118 61180
Base Rear Panel 147/177 61181
Base Rear Panel 206/236 61182
Base Rear Panel 288 61183
Burner Access Panel 88/118 50271
Burner Access Panel 147/177 50272
Burner Access Panel 206/236 50273
Burner Access Panel 288 50274
Burner Tray Rear Support 118 50300
Burner Tray Rear Support 88 50301
Burner Tray Rear Support 177 50302
Burner Tray Rear Support 147 50303
Burner Tray Rear Support 236 50304
Burner Tray Rear Support 206 50305
Burner Tray Rear Support 288 50306
Burner Tray Left Side Rail 50296
Burner Tray Right Side Rail 50295
16 Burner 50192
Burner with Pilot Bracket (Standing Pilot) 50162
Burner with Pilot Bracket 50163
Item
Description
Stock
No. Code
12. REPAIR PARTS
Item
Description
Stock
No. Code
19
11
12
13
17
15
14
18
22
1-10
